12V DC-DC Adapter Board with USB Type-C Output
DC-DC adapter board with 12V input via a PHR2 connector and USB Type-C / USB 2.0 outputs. The PCB measures 35.4 x 31 x 1.0 mm and is designed for 5V conversion. Suitable for 12V to 5V adapter applications.
Product Type
DC-DC Adapter Board
PCB Size
35.4 x 31 x 1.0 mm
Input Voltage
12V
Input Interface
PHR2 connector
Output Interface
USB Type-C, USB 2.0
Application
5V conversion
Factory manufacturing process for custom electronics.
Pasoon supports each product project with a practical workflow from sample review and engineering confirmation to assembly, inspection and delivery preparation.
01
Project Review
Check product photos, drawings, PCB dimensions, BOM, connector requirements and target application before quotation.
02
Engineering Confirmation
Review assembly route, component options, enclosure fit, soldering points and test requirements before sampling.
03
Assembly & Inspection
Carry out SMT, DIP, connector mounting, soldering inspection and process checks according to the product structure.
04
Testing & Delivery
Complete functional verification, inspection records, anti-static packaging, labels and delivery preparation for repeat supply.
